KR TITAN ultra

The specialist for handling heavy loads. The industrial robot moves payloads of up to 1500 kg over long distances and impresses with its low weight.

The strongest industrial robot in the KUKA portfolio

Heavyweights are no problem for him: the new KR TITAN ultra sets new standards in the KUKA portfolio. Its energy-efficient design reduces operating costs and supports sustainable production processes. At the same time, its reliability contributes to high availability – whether in automotive production, in precise processes in battery manufacturing, or in handling large-format modules in photovoltaics. Wherever heavy components need to be moved, it impresses with its robust performance and consistent operational reliability.

1000 - 1500 Load capacity [kg]

3226 - 4218 Reach [mm] (arm length)

Advantages

High load capacity, small footprint

The KR TITAN ultra moves very high payloads with a small footprint. The heavy-duty robot lifts parts weighing up to 1500 kg with a dead weight of just 4.5 t.

High Inertia meets High Payload

Even large and very heavy parts with high moments of inertia are always under control thanks to the heavy-duty robot's rigid design with double swing arms.

More reach

The KR TITAN ultra has a reach of up to 4200 mm in the version with a payload of 1000 kg. The robot is also available with a reach of 3700 mm (1250 kg payload) and 3200 mm (1500 kg).

Foundry variant for versatile use

The foundry version enables the robot to be used under extreme production conditions and withstands environmental influences such as dust, heat and moisture.

Modular design

Modular design ensures high compatibility and scalability between robot series
Identical parts, e.g., available in KR FORTEC ultra
Low TCO thanks to standardized components

Reduction in TCO and maintenance costs

Low energy consumption for efficient operation
High MTBF thanks to durable components
Short MTTR for fast recovery
Maintenance-optimized design with easy access to relevant components
Few recurring service tasks required

KR TITAN ultra (6 axes) - technical data

KR 1000 R4200-2 F

Total load

1000 kg

Maximum reach

4218 mm

Version environment

Foundry

Downloads

Download Center

Total load 1000 kg
Maximum reach 4218 mm
Construction type Standard
Version environment Foundry
Mounting positions Floor

Protection class IP 65, IP 67
Downloads Download Center
Controller
- KR C5

KR 1250 R3700-2 F

Total load

1250 kg

Maximum reach

3726 mm

Version environment

Foundry

Downloads

Download Center

Total load 1250 kg
Maximum reach 3726 mm
Construction type Standard
Version environment Foundry
Mounting positions Floor

Protection class IP 65, IP 67
Downloads Download Center
Controller
- KR C5

KR 1500 R3200-2

Total load

1500 kg

Maximum reach

3226 mm

Version environment

Standard

Downloads

Download Center

Total load 1500 kg
Maximum reach 3226 mm
Construction type Standard
Version environment Standard
Mounting positions Floor

Protection class IP 65, IP 67
Downloads Download Center
Controller
- KR C5

KR 1500 R3200-2 F

Total load

1500 kg

Maximum reach

3226 mm

Version environment

Foundry

Downloads

Download Center

Total load 1500 kg
Maximum reach 3226 mm
Construction type Standard
Version environment Foundry
Mounting positions Floor

Protection class IP 65, IP 67
Downloads Download Center
Controller
- KR C5
